ZEISS OPTICS

German design engineering manufacturing and ultimate craftsmanship comes to life in these sophisticated V8 scopes with a highly advantageous 8x zoom ratio. The distinctly innovative optics utilize exotic glass types from SCHOTT glass consisting of multiple FL (fluoride) and HT (high-transmission) lens elements. The optical system yields an impressively bright image with a guaranteed light transmission value of 92%. An immediate advantage of these designs is the extra-large eye box that allows for faster target acquisition. - ZEISS' benchmark model of the V8 product line. With up to 35x magnification the V8 4.8-35x60 NA offers the ultimate in long-range target identification and truly extends long-range hunting capabilities. The optical system offers most excellent detailed image resolution throughout the entire 35x range. - Performance - Magnification 4.8-35 � - Effective lens diameter 48.1-60 mm - Light transmission 92% - Exit pupil diameter 9.9-1.7 mm - Twilight factor 13.6-45.8 - Field of view at 100 m (yds) 8.6-1.2 m (26- 4 ft) - Objective viewing angle 4.9�-0.7� - Diopter adjustment range -3.5 | + 2 dpt - Eye relief 92 mm (3.6 ) - Parallax setting 50 m-infinity (54 yds-infinity) - Vertical adjustment range at 100 m 140 cm - Lateral adjustment range at 100 m 85 cm - Adjustment per click at 100 m 0.25 MOA - Centre tube diameter 34 mm - Eyepiece tube diameter 46 mm - Objective tube diameter 67 mm - Features - LotuTec | Nitrogen filled + | + - Water resistance 400 mbar - Physical - Operating temperature -25�C | + 50�C (-13�F | + 122�F) - Length 399 mm (15.7 ) - Weight (without inner rail) 995 g (35.1 oz) - Weight (with inner rail) 1015 g (35.8 oz)
